Wall Pocket Tables

Free up dining space for other activities.

  • Multiple Locking Systems – Track Lock® provides a one-step release from the wall pocket and convenient, secure return.
  • Intermediate Track Lock – Automatically secures tables and benches in pockets during storage.
  • Z-Lock automatically captures table and benches, aligning and securing table and benches to the top of pocket.
  • Bottom Safety Latch – Latches outer table and benches with inner table and bench leaf.
  • Keyed Mullion Locks – Secure outer table and benches in storage position from unauthorized use.
  • Storage Capacity – A single 14 foot table and bench system stores in just 6 inches of depth. Available in double, triple and quad units.
  • EdgeGuard™ – EdgeGuard (standard) with 3⁄4” M3 particle board.

Site Survey Forms

Additional information

Seat Type

Bench

Table Height

27", 29"

Table Depth

30"

Edges

EdgeGuard

Wheelchair Accessible

Yes, specify when ordering

Table Length

12' (144")

Wall Pocket Tables

Tables, Benches, Pockets
Part #DescriptionRevitCAD
39075145 Degree Right-Hand Corner Assembly - 87A single depth
39075245 Degree Left-Hand Corner Assembly - 87A single depth
39075645 Degree Right-Hand Corner Assembly - 87A double depth
39075745 Degree Left-Hand Corner Assembly - 87A double depth
40M23273014Wall Pocket Table 27”H x 30”W x 14’L
40M23293014Wall Pocket Table 29”H x 30”W x 14’L
40M23303014Wall Pocket Table 30”H x 30”W x 14’L
41M23273013Retro-Fit Table 27”H x 30”W x 13.5’L
41M23293013Retro-Fit Table 29”H x 30”W x 13.5’L
42M23151214Wall Pocket Bench 15”H x 12”W x 14’L (each)
42M23171214Wall Pocket Bench 17”H x 12”W x 14’L (each)
43M23151213Retro-Fit Bench 15”H x 12”W x 13.5’L (each)
43M23151213Retro-Fit Bench 15”H x 12”W x 13.5’L (each)
43M23171213Retro-Fit Bench 17”H x 12”W x 13.5’L (each)
43M23171213Retro-Fit Bench 17”H x 12”W x 13.5’L (each)
44M23273012Wall Pocket Table 27”H x 30”W x 12’L
44M23293012Wall Pocket Table 29”H x 30”W x 12’L
45M23272613Retro-Fit Table 27”H x 26”W x 13.5’L
45M23292613Retro-Fit Table 29”H x 26”W x 13.5’L
45M23302613Retro-Fit Table 30”H x 26”W x 13.5’L
46M23151212Wall Pocket Bench 15”H x 12”W x 12’L
46M23171212Wall Pocket Bench 17”H x 12”W x 12’L
48M23151211Wall Pocket Bench 15”H x 12”W x 11’L (each)
48M23171211Wall Pocket Bench 17”H x 12”W x 11’L (each)
70M23273012Wall Pocket Table 27”H x 30”W x 12’L
70M23273014Wall Pocket Table 27”H x 30”W x 14’L
70M23293012Wall Pocket Table 29”H x 30”W x 12’L
70M23293014Wall Pocket Table 29”H x 30”W x 14’L
71M23273013Wall Pocket Table 27”H x 30”W x 13.5L
71M23293013Wall Pocket Table 29”H x 30”W x 13.5’L
72M03151212Wall Pocket Bench 15”H x 12”W x 12’L (each)
72M23151214Wall Pocket Bench 15”H x 12”W x 14’L (each)
72M23171212Wall Pocket Bench 17”H x 12”W x 12’L (each)
72M23171214Wall Pocket Bench 17”H x 12”W x 14’L (each)
73M23151213Wall Pocket Bench 15”H x 12”W x 13.5’L (each)
73M23171213Wall Pocket Bench 17”H x 12”W x 13.5’L (each)
81R031410Single Recessed Pocket - 1 Table, no Bench
81R031420Double Recessed Pocket - 2 Table, no Bench
81R031430Triple Recessed Pocket - 3 Table, no Bench
82R031412Single Half Recessed Pocket - 1 Table, 2 Benches
82R031424Double Half Recessed Pocket - 2 Tables, 4 Benches
83R031411LSingle Recessed Pocket - 1 Table, 1 Left-Side Bench
83R031411RSingle Recessed Pocket - 1 Table, 1 Right-Side Bench
84R031212Single Recessed Wall Pocket 12'L
84R031224Double Recessed Wall Pocket 12'L
84R031236Triple Recessed Wall Pocket 12'L
85A031212Single Against Wall Pocket 12'L
85A031224Double Against Wall Pocket 12'L
85A031236Triple Against Wall Pocket 12'L
86R031412Single Recessed Wall Pocket 14'L
86R031424Double Recessed Wall Pocket 14'L
86R031436Triple Recessed Wall Pocket 14'L
86R031448Quadruple Recessed Wall Pocket 14'
87A031412Single Against Wall Pocket 14'
87A031412 FLR18Single Depth Filler Panel System 18"W x 14'L
87A031412 FLR20Single Depth Filler Panel System 20"W x 14'L
87A031412 FLR24Single Depth Filler Panel System 24"W x 14'L
87A031412 FLR30Single Depth Filler Panel System 30"W x 14'L
87A031412 FLR36Single Depth Filler Panel System 36"W x 14'L
87A031412FTOPSingle Flat Top Against Wall Pocket
87A031424Double Against Wall Pocket
87A031424 FLR18Double Depth Filler Panel System 18"W x 14'L
87A031424 FLR20Double Depth Filler Panel System 20"W x 14'L
87A031424 FLR24Double Depth Filler Panel System 24"W x 14'L
87A031424 FLR30Double Depth Filler Panel System 30"W x 14'L
87A031424 FLR36Double Depth Filler Panel System 36"W x 14'L
87A031424FTOPDouble Flat Top Against Wall Pocket
87A031436Triple Against Wall Pocket 14'L
87A031448Quadruple Against Wall Pocket 14'L
88R031312Single Retro-Fit Pocket 13.5'L
88R031324Double Retro-Fit Pocket 13.5'L
89R031312Single Retro-Fit Pocket, Shallow 13.5'L
89R031324Double Retro-Fit Pocket 13.5'L
89R031336Triple Retro-Fit Pocket 13.5'L
89R031348Quad Retro-Fit Pocket 13.5'L
90R031312Single Retro-Fit Pocket, Wide 13.5'L
90R031324Double Retro-Fit Pocket, Wide 13.5'L
90R031336Triple Retro-Fit Pocket, Wide 13.5'L
91A031211LSingle Against Wall Pocket - 1 Table, 1 Left Bench
91A031211RSingle Against Wall Pocket - 1 Table, 1 Right Bench
92A031410Single Against Wall Pocket - 1 Table, no Bench
92A031420Single Against Wall Pocket - 2 Table, no Bench
92A03143003-Slope Top Onwall Pocket 3Tbl 0Bch 14' Custom
96A031312FTOP03-Flat Top Onwall 13.5' Single Depth
96A031324FTOP03-Flat Top Onwall 13.5' Double Depth
97R03132003-26W Table Only 13.5' Double Depth
98R03132403-Partial Recess 13.5' Double Depth 2 Inch Side Flange

Move tables into the wall.

Years of experience in building these specialty tables has made us experts in problem solving.
